The drainage and disposal system
They say that the 21st century is water and the shortage of water causing from the warming of the earth and so the balancing of the lasting economical action and the demand of water is our essential problem.
So we reuse of the drainage water from factties whichi is disposed not only of normal cleaning system but of the hifh level disposal and cleaning system
|
 |
|
The first and second drainage system
The first drainage system is to dispose of solid material and oil and to preserve the rest at the normal temperature.
The second drainage system is to dispose of nitrogen and phosphorus and organic material from salts. |
 |
The high level institute of making water and disposing water
The organic matter of a small amount of suspended solid and the polymer is removed by precipitation and the living thing filtration processing in the advanced processing equipment. |
 |
|
The well water tank and the institute of reuse
The water which is disposed of dust and dirt is not freely to frow away but to preserve in the tanks and to reuse in the factory as the water resources,
And we set the tank to reserve the well water. |
 |
The control room
In the controle room they control the unit of drainage and manage the operation data of drainage and the deodorization.
And in the control room they make meteorological observations and collect the data and analize it because the temperature and the humidity and etc. are the important element to keep the manufactured goods in high quolity. |
 |
|
The device of the system of deodoriztion
The device of the system of deodorization is indispensable to keep the circumstances of
life at any region comfortable. We try to keep the circumstances of life clean, thinking
of our of our painful experiences in our past and adopting the ultra advancing technique of the deodorization.
In order to defend the leak of smell into the outer world, we keep the inside of the factory under the normal pressure and use the three kinds of instituts of deoderization.
We divide every smell into three kinds; these are the higher and normal and lower densities, and we collect the smell through the duct adopting the method fitting to each place and way. |
 |
|
The institute of deodorization of higher density
All the main machinary and tools of the plant are completely sealed and the higher density smell containing oils and fats are oxidized and disolved into carbonic acid gas and steam under the higher temparature aa (850 950 C )through the rolling regeneration and considerable method of dederization. |
 |
The institute of derization of normal density smell
The ventilation smell in the factory or the institute of treating the drainage is got rid
of with the metod of washing with water and of distilation firstly and with the method of washing with acid and alkali.
Smell is got rid of with the method of neutralization and oxidation.
In our business world we limit the treatment of deoderiztion within the factory and within the hour of working time, but in our factory we operate the machine during the whole hours of working. |
 |
|
The institute of deorderization of lower density of smell
The ventilation smell of the material room and the freezing room is comparatively lower
density and so we use the ventilated air as the fresh air of the steam boiler and exidize and disolve it into carbonic acid gas and steam with the method of boiler-typed deorderization under higher temperature (800度―900度) and defuse them into the circumstances. |
 |
The duct
The smell of higher density containing the smell of oils and fats is led directly into the oil-mist filter and absorbed into the higher density deoderiztion tool by the duct.
The smell of normal density and lower density is absorbed into each institute by the ventilation fan and the through the duct settled on the ceiling. |
 |
|
